Speed-Chek Tube Tester 2413
Triplett Electrical Instrument Co.; Bluffton (OH)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Triplett Electrical Instrument Co.; Bluffton (OH)
- Year
- 1946/1947
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 176049
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Speed-Chek Tube Tester 2413 - Triplett Electrical Instrument
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 10 x 5.5 x 10 inch / 254 x 140 x 254 mm
- Notes
-
Standardized value test, short and open element test and transconductance comparison test. 4" square "lifetime guaranteed" meter. Tube chart 8" x 9".
Line voltage adjustment control. Filament voltages 0,25 to 110 V in 19 steps.
Square line series metal case, two-twone enamel finish. Detachable cover.
- Net weight (2.2 lb = 1 kg)
- 5.1 kg / 11 lb 3.7 oz (11.233 lb)
- Mentioned in
- Radio Retailing (Radio & Television R.) (May 1946 page 103. November 1946 page 140.)
- Literature/Schematics (2)
- -- Original prospect or advert
- Author
- Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
