Plattenspieler ZH544A

ID = 11107

Plattenspieler ZH544A; Zerdik; Wien (ID = 39195) R-Player

Plattenspieler ZH544A; Zerdik; Wien (ID = 774462) R-Player

{gbW: "484", gbH: "700", mW: "259", mH: "375", kb: "42 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien", title: "Zerdik; Wien Plattenspieler ZH544A from Bernhard Beier (1)", ite: "1"} {gbW: "760", gbH: "700", mW: "407", mH: "375", kb: "112 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien", title: "Zerdik; Wien Plattenspieler ZH544A from Bernhard Beier (1)", ite: "1"} {gbW: "421", gbH: "700", mW: "225", mH: "375", kb: "41 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien:[br]Zerdik Type ZH 544A", title: "Zerdik; Wien Plattenspieler ZH544A from Alois Steiner (1)", ite: "1"} {gbW: "933", gbH: "699", mW: "500", mH: "375", kb: "73 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien", title: "Zerdik; Wien Plattenspieler ZH544A from Hannes Wurnitsch (1)", ite: "1"} {gbW: "525", gbH: "700", mW: "281", mH: "375", kb: "42 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien", title: "Zerdik; Wien Plattenspieler ZH544A from Hannes Wurnitsch (1)", ite: "1"} {gbW: "630", gbH: "505", mW: "467", mH: "375", kb: "44 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien:[br]Zerdik Phonokoffer ZH544A", title: "Zerdik; Wien Plattenspieler ZH544A from Gerhard Heigl (1)", ite: "1"} {gbW: "491", gbH: "694", mW: "265", mH: "375", kb: "54 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien:[br]Zerdik Phonokoffer ZH544A", title: "Zerdik; Wien Plattenspieler ZH544A from Gerhard Heigl (1)", ite: "1"} {gbW: "480", gbH: "640", mW: "281", mH: "375", kb: "123 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien:[br]Zerdik ZH544A", title: "Zerdik; Wien Plattenspieler ZH544A from Alois Steiner (1)", ite: "1"} {gbW: "640", gbH: "480", mW: "500", mH: "375", kb: "115 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien:[br]Zerdik ZH544A (Typenschild)", title: "Zerdik; Wien Plattenspieler ZH544A from Alois Steiner (1)", ite: "1"} {gbW: "600", gbH: "546", mW: "412", mH: "375", kb: "64 KB", notes: "For model Plattenspieler ZH544A, Zerdik; Wien", title: "Zerdik; Wien Plattenspieler ZH544A from Hermann Schagerl (1)", ite: "1"}

Next pictures

Plattenspieler ZH544A; Zerdik; Wien (ID = 53709) R-Player

Zerdik; Wien: Plattenspieler ZH544A [R-Player] ID = 53709 484x700

For model Plattenspieler ZH544A, Zerdik; Wien

Country:

Austria

Manufacturer/Brand:

Zerdik; Wien

Year: 1955/1956

Type: Recorder and/or Player

Valves / Tubes

3: EF86 EL84 EZ80

Principle	Audio-Amplification
Wave bands	- without
Details	Rec.Player+Audio.Amp+LS
Power type and voltage	Alternating Current supply (AC) / 110; 130; 150; 220 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org	Model: Plattenspieler ZH544A - Zerdik; Wien
Material	Various materials
Shape	Tablemodel, low profile (big size).
Dimensions (WHD)	330 x 160 x 370 mm / 13 x 6.3 x 14.6 inch
Notes	Plattenspieler Philips AG2002.
Net weight (2.2 lb = 1 kg)	3.7 kg / 8 lb 2.4 oz (8.15 lb)
Collectors' prices	1 Collector price (for members Radiomuseum.org)
External source of data	E. Erb 3-907007-36-0
Source of data	Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1)	-- Original-techn. papers.

All listed radios etc. from Zerdik; Wien
Here you find 161 models, 102 with images and 72 with schematics.

Collection of Bernhard Beier (A)
Collection of Alois Steiner (A)
Collection of Hermann Schagerl (A)
Collection of Albert Weiss (A)
Collection of Hannes Wurnitsch (A)
Collection of Gerhard Heigl (A)

Forum contributions about this model
Zerdik; Wien: Plattenspieler ZH544A
Threads: 1 | Posts: 1

Hits: 370 Replies: 0

zerdik: ZH544A (ZH 544A); Plattenspieler

Leo Brtna
31.Jul.07

zerdik: ZH544A (ZH 544A); Plattenspieler

Als Allstromgerät: gleiches Laufwerk, gleicher Koffer mit folgender Röhrenbestückung:

UBC41 UL41 UY41.
