20X136 Ch= 20Y1

20X136 Ch= 20Y1; Admiral brand (ID = 749130) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749131) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749132) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749133) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749134) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749135) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749136) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749137) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749138) TV Radio

20X136 Ch= 20Y1; Admiral brand (ID = 749139) TV Radio
20X136 Ch= 20Y1; Admiral brand (ID = 1605255) TV Radio
Use red slider bar for more.
20X136 Ch= 20Y1; Admiral brand (ID = 1605255) TV Radio
Admiral brand: 20X136 Ch= 20Y1 [TV Radio] ID = 1605255 887x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model 20X136 Ch= 20Y1, Admiral (brand) Continental Radio & Television Co.:
Quelle: SAMS

Country:  United States of America (USA)
Manufacturer / Brand:  Admiral (brand) Continental Radio & Television Co.
alternative name

Continental Radio & TV
Year: 1949 Type: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 19: 6AG5 6J6 6AU6 6AU6 6AU6 6AL5 6AU6 12LP4 6AU6 6AL5 6SN7GT 6AS5 12AU7 12AU7 6SN7GT 6BG6G 6W4GT 1X2 5U4G
Principle Super-Heterodyne (Super in general); ZF/IF 25750/21250/4500 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110-120 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: 20X136 Ch= 20Y1 - Admiral brand Continental
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes The family of Admiral TV models using the 20Y1 chassis with 12LP4 12-inch CRT includes three wooden table models: 20X135 (walnut), 20X136 (mahogany), and 20X137 (blond); and three wooden consoles: 20X145 (walnut), 20X146 (mahogany), and 20X147 (blond).

The 20Y1 chassis is similar to the 20X1 chassis (for 10-inch CRT) and has a 12-channel tuner for the U.S. VHF TV band and uses intercarrier sound IF.
Circuit diagram reference Photofact Folder, Howard W. SAMS
Literature/Schematics (1) Rider TV Admiral 4-38; SAMS set 100 folder 1
Literature/Schematics (2) Photofact Folder, Howard W. SAMS (Set 91A Folder 1 1950)

Model page created by Thomas Albrecht. See "Data change" for further contributors.
