• Country
• Finland

• Manufacturer / Brand
• Oy Helvar; Helsinki

• Year
• 1955

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 192454

• Number of Tubes
• 5

• Valves / Tubes
• DK92 DF91 DAF91 DL94 UL41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Line / Batteries (any type) / 127; 220 / 1,5 & 90 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Celeston Vagabond 5562MW - Oy Helvar; Helsinki

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 305 x 255 x 155 mm / 12 x 10 x 6.1 inch

• Author
• Model page created by Timo Rantasaari. See "Data change" for further contributors.

• Other Models

• Here you find 254 models, 215 with images and 93 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Oy Helvar; Helsinki
