• Country
• Germany

• Manufacturer / Brand
• Kaiser KG, W. bzw. Kaiser-Werke Gebr. Kaiser; Kenzingen bzw. Villingen etc.

• Year
• 1962 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 217699

• Number of Tubes
• 9

• Valves / Tubes
• ECC85 ECH81 EBF89 ECC81 EM84 ECC83 EL84 EL84 EZ81

• Main principle
• Superheterodyne (common); Export model

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• 6 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Kaiser Stereo Multiplex Six Speaker System - Kaiser KG, W. bzw. Kaiser-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 560 x 360 x 240 mm / 22 x 14.2 x 9.4 inch

• Notes
• Kaiser Stereo Multiplex - Six Speaker System;
  Export model, built-in multiplex adapter. Stereo indicator lamp.
  Inputs for phono, tape. External speaker outputs.
  FM: 88...108 MHz, SW: 5.9...16 MHz.
  This model was also sold in the USA under the brand name Majestic Continental.

• Author
• Model page created by Jim Ray. See "Data change" for further contributors.
