Blues 070 90AL070 /50

Philips Radios - Deutschland

  • Year
  • 1978
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 194093
    • Brand: Deutsche Philips-Ges.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Dry Batteries / 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 0.3 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Blues 070 90AL070 /50 - Philips Radios - Deutschland
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 150 x 80 x 40 mm / 5.9 x 3.1 x 1.6 inch
  • Notes
  • Ferritantenne für MW, Teleskopantenne für UKW, Anschluss für Kleinhörer.
  • Net weight (2.2 lb = 1 kg)
  • 0.3 kg / 0 lb 10.6 oz (0.661 lb)
  • Source of data
  • -- Original prospect or advert
  • Mentioned in
  • Prospekt: Alle Klänge dieser Welt, Ausgabe 1978/79
  • Author
  • Model page created by Günter Döring. See "Data change" for further contributors.
