• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1966

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 86803

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 14

• Valves / Tubes
• PC900 PCF801 PCF201 PCF200 PCL84 PL84 PCL86 PCH200 PCL85 PCF802 PL500 PY81 DY87 A47-11W

• Number of Transistors
• 3

• Semiconductors
• AF186 AF186 AF126

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Format 19 19TA501A /00 /70 Ch= F2 - Philips - Österreich

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 560 x 435 x 295 mm / 22 x 17.1 x 11.6 inch

• Notes

• Fernsehband VHF (I+III), UHF (IV/V). 19-Zoll-Rechteckbildröhre.

  2 Ausführungen:
  /00 = dunkel-glänzend,
  /70 = hell-matt.

  Parallelgerät zum Horny W48T105A.

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
