Television / FM Sweep Generator WR-69-A

RCA (RCA Victor Co. Inc.); New York (NY)

  • Year
  • 1957
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 137148
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Television / FM Sweep Generator WR-69-A - RCA RCA Victor Co. Inc.; New
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 13.63 x 10 x 7 inch / 346 x 254 x 178 mm
  • Notes
  • RCA WR-69A, Television/FM Sweep Generator;
  • Price in first year of sale
  • 295.00 $
  • Source of data
  • -- Original prospect or advert
  • Mentioned in
  • RCA Test Equipment and Accessories ~1965
  • Literature/Schematics (1)
  • PF Reporter, Oct. 1957, page 86 "New from RCA is the WR-69A"
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
