Rialto 350 17110

Rialto 350 17110; Schaub und Schaub- (ID = 780723) Radio

Rialto 350 17110; Schaub und Schaub- (ID = 780724) Radio

Rialto 350 17110; Schaub und Schaub- (ID = 780725) Radio

Rialto 350 17110; Schaub und Schaub- (ID = 780726) Radio
Rialto 350 17110; Schaub und Schaub- (ID = 24277) Radio Rialto 350 17110; Schaub und Schaub- (ID = 493627) Radio
Rialto 350 17110; Schaub und Schaub- (ID = 1015725) Radio Rialto 350 17110; Schaub und Schaub- (ID = 1480855) Radio
Rialto 350 17110; Schaub und Schaub- (ID = 1480857) Radio Rialto 350 17110; Schaub und Schaub- (ID = 1480860) Radio
Rialto 350 17110; Schaub und Schaub- (ID = 1480862) Radio Rialto 350 17110; Schaub und Schaub- (ID = 1480867) Radio
Rialto 350 17110; Schaub und Schaub- (ID = 1480870) Radio Rialto 350 17110; Schaub und Schaub- (ID = 1480873) Radio
Use red slider bar for more.
Rialto 350 17110; Schaub und Schaub- (ID = 24277) Radio
Schaub und Schaub-: Rialto 350 17110 [Radio] ID = 24277 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rialto 350 17110, Schaub und Schaub-Lorenz

Country:  Germany
Manufacturer / Brand:  Schaub und Schaub-Lorenz
Year: 1959/1960 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EF89 EABC80 EC92 EL95 EL95 EM84
Principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Rialto 350 17110 - Schaub und Schaub-Lorenz
Material Wooden case
Dimensions (WHD) 620 x 395 x 260 mm / 24.4 x 15.6 x 10.2 inch
Net weight (2.2 lb = 1 kg) 11.5 kg / 25 lb 5.3 oz (25.33 lb)
Price in first year of sale 359.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1959/60

All listed radios etc. from Schaub und Schaub-Lorenz
Here you find 882 models, 723 with images and 596 with schematics.
