MC44829

Information - Help
ID = 67901

Country:
United States of America (USA)
Brand: Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
Tube type:  IC - Integrated Circuit
Identical to MC44829

Base Wires
Description

Aufbau/Content: IC (__ Trans., __ Widerst., __ Dioden, __ Kond.);
Form/Case/Outline: SOP-14 (MC44829D);
Applikation/Type: TV and VCR I²C PLL Tuning Circuit with 1.3 GHz Prescaler and Mix-Osc Decoder;
Daten/electr.data: Vcc: 5 V; Icc: 35 mA; Pd: __ mW; t op: -20...+80 °C;
-


Weight 1 g / 0.04 oz
Information source - - Manufacturers Literature

MC44829: Motorola
Günther Stabe † 19.8.20

mc44829_s.png MC44829: Motorola
Günther Stabe † 19.8.20

MC44829: Motorola
Günther Stabe † 19.8.20

Usage in Models 1= 1999??

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):1
