For model 2440U, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Grundig model 2440U - Front view

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1964/1965 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM87 EL84
Principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Wave bands Broadcast, Short Wave plus FM.
Details
Power type and voltage Alternating Current supply (AC) / 115-120 Volt
Loudspeaker 3 Loudspeakers / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: 2440U - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes Similar to model 2420U. This model, 2440U has a speaker #1 = 6"x9", Speaker #2 = 3" electrostatic, Speaker #3 = 3" electrostatic. It is a typical export version of Grundig.
Collectors' prices
Source of data - - Data from my own collection
Literature/Schematics (1) Photofact Folder, Howard W. SAMS

Model page created by Jeff Miller. See "Data change" for further contributors.

All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
Here you find 5046 models, 4245 with images and 3451 with schematics for wireless stes etc. French TSF for Télégraphie sans fil.




Forum contributions about this model
Grundig Radio-: 2440U
Threads: 1 | Posts: 2
Hits: 912     Replies: 1
grundig: 2440U (2440 U);
Leo Van Houten † 2013
08.Dec.10
  1

I have a FM problem with a Grundig 2440 and 2520. Both use the AM section for FM. Both radios work fine on AM/SW but are dead on FM, not even air noise. Is this a common problem and were can I look to fix it. Thank you Leo

Bryce Ringwood
13.Dec.10
  2

Hi Leo,

Since the AM/SW sections are all working, the possible culprits would seem to be the FM discriminator, the switching arrangements (dirty contacts) or the FM Tuner (ECC85).

If you have an FM Signal generator, you could remove the ECC85 and inject an FM modulated signal 10.7 MHz at the grid of the ECH81. If all seems well then its not the discriminator. (EABC80). If you don't have an FM signal generator, sometimes putting an aerial on the grid will send shortwave stations on 10.7 MHz through the system. (This is not a great way to do things though - might be better to knock up a makeshift sig gen.)

Next, you could try replacing the ECC85 and tuning the radio to 90MHz. Using another radio tune to 100.7 MHz to see if the FM local oscillator is behaving. (Assuming LO is on high side). Or tune to 100.7MHz and Listen for the LO on 90MHz.

Check the tuner for broken feedthrough caps and wires missing. Check the ECC85 (or substitute a known good one). If the discriminator doesn't work, try substituting the EABC80. Check voltages and caps in the tuner.

Those are the simple things. Hope you come right. - Bryce
