5E61-DU

5E61-DU; Stern-Radio Rochlitz (ID = 153662) Radio
5E61-DU; Stern-Radio Rochlitz (ID = 57363) Radio 5E61-DU; Stern-Radio Rochlitz (ID = 289598) Radio
5E61-DU; Stern-Radio Rochlitz (ID = 412419) Radio 5E61-DU; Stern-Radio Rochlitz (ID = 154086) Radio
5E61-DU; Stern-Radio Rochlitz (ID = 155190) Radio 5E61-DU; Stern-Radio Rochlitz (ID = 160194) Radio
5E61-DU; Stern-Radio Rochlitz (ID = 289597) Radio 5E61-DU; Stern-Radio Rochlitz (ID = 289599) Radio
5E61-DU; Stern-Radio Rochlitz (ID = 413612) Radio 5E61-DU; Stern-Radio Rochlitz (ID = 1085564) Radio
Use red slider bar for more.
5E61-DU; Stern-Radio Rochlitz (ID = 57363) Radio
Stern-Radio Rochlitz: 5E61-DU [Radio] ID = 57363 527x325
Select picture or schematic to display from thumbnails on the right and click for download.
For model 5E61-DU, Stern-Radio Rochlitz, VEB, RFT, (Ostd.) - vorm. Graetz AG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Rochlitz, VEB, RFT, (Ostd.) - vorm. Graetz AG
Year: 1950–1952 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH11 UBF11 UCL11 or UEL51 UM11 UY11 or
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage AC/DC-set / 127/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 5E61-DU - Stern-Radio Rochlitz, VEB, RFT
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 550 x 330 x 270 mm / 21.7 x 13 x 10.6 inch
Notes Vorbereitet für den Einbau eines UKW-Vorsatzgerätes, UKW-Bereich linear auf der Skala. Wahlweise auch mit Trockengleichrichter (Selengleichrichter), Schaltung/Bestückung entsprechend geändert - siehe techn. Unterlagen.
Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
Collectors' prices
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967

Model page created by Jens Dehne. See "Data change" for further contributors.
