Dunga 5925

Dunga 5925; ABC - Rádio e (ID = 425915) Radio
Dunga 5925; ABC - Rádio e (ID = 425913) Radio Dunga 5925; ABC - Rádio e (ID = 425914) Radio
Dunga 5925; ABC - Rádio e (ID = 786331) Radio
Use red slider bar for more.
Dunga 5925; ABC - Rádio e (ID = 425913) Radio
ABC - Rádio e: Dunga 5925 [Radio] ID = 425913 933x623
Select picture or schematic to display from thumbnails on the right and click for download.
For model Dunga 5925, ABC - Rádio e Televisão do Nordeste S/A:
Front view of Radio ABC Model Dunga 5925

Country:  Brazil
Manufacturer / Brand:  ABC - Rádio e Televisão do Nordeste S/A
Year: 1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AV6 50C5 35W4
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Dunga 5925 - ABC - Rádio e Televisão do
Material Moulded (Bakelite or Plastics)
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 280 x 190 x 140 mm / 11 x 7.5 x 5.5 inch
Notes Lower front 2 band slide rule dial, frontal left on/off/volume and right dial and back band knobs, upper losangle cut outs grill.
Source of data -- Schematic

Model page created by Carlos Lazarini. See "Data change" for further contributors.
