Stereo Control Amplifier C-200

• Country
• Japan

• Manufacturer / Brand
• Accuphase Laboratory; Yokohama

• Year
• 1973

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 163087

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 80

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100; 117; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Control Amplifier C-200 - Accuphase Laboratory; Yokohama

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 445 x 152 x 355 mm / 17.5 x 6 x 14 inch

• Notes
• Stereo Pre Amplifier.
  80 Transistors, 35 Diodes.

• Net weight (2.2 lb = 1 kg)
• 14 kg / 30 lb 13.4 oz (30.837 lb)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
