Stereo Pre Amplifier C-11

Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 637575) Ampl/Mixer Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 677515) Ampl/Mixer
Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 637577) Ampl/Mixer Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 637579) Ampl/Mixer
Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 677513) Ampl/Mixer Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 699038) Ampl/Mixer
Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 1772762) Ampl/Mixer Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 1772766) Ampl/Mixer
Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 1772767) Ampl/Mixer Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 1772770) Ampl/Mixer
Use red slider bar for more.
Stereo Pre Amplifier C-11; Accuphase Laboratory (ID = 637575) Ampl/Mixer
Accuphase Laboratory: Stereo Pre Amplifier C-11 [Ampl/Mixer] ID = 637575 933x287
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Pre Amplifier C-11, Accuphase Laboratory; Yokohama:
Accuphase Prospekt

Country:  Japan
Manufacturer / Brand:  Accuphase Laboratory; Yokohama
Year: 1989 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 37:
Main principle Audio-Amplification
Wave bands - without
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 100; 117; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Pre Amplifier C-11 - Accuphase Laboratory; Yokohama
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 445 x 95 x 325 mm / 17.5 x 3.7 x 12.8 inch
Notes Wireless Remote Control (RC-3).
15 FET's, 33 IC's, 59 Diodes.
Net weight (2.2 lb = 1 kg) 9.3 kg / 20 lb 7.8 oz (20.485 lb)

Model page created by Franz Scharner. See "Data change" for further contributors.



All listed radios etc. from Accuphase Laboratory; Yokohama
Here you find 107 models, 106 with images and 26 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
