Super Audio CD Player DP-77

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083400) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083401) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083402) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083403) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2480854) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2480855) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2480856) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2480857) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2480858) R-Player

Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2480859) R-Player
Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083399) R-Player Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083406) R-Player
Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083407) R-Player
Use red slider bar for more.
Super Audio CD Player DP-77; Accuphase Laboratory (ID = 2083399) R-Player
Accuphase Laboratory: Super Audio CD Player DP-77 [R-Player] ID = 2083399 1400x1144
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super Audio CD Player DP-77, Accuphase Laboratory; Yokohama:
Accuphase Sales Brochure

Country:  Japan
Manufacturer / Brand:  Accuphase Laboratory; Yokohama
Year: 2003 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Super Audio CD Player DP-77 - Accuphase Laboratory; Yokohama
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 475 x 151 x 397 mm / 18.7 x 5.9 x 15.6 inch
Notes

Frontloading Single Compact Disc Player Model Accuphase DP-77.
Disc format: CD, SACD
Digital converter: 24-bit MDS plus
Frequency response: 0.5Hz to 50kHz
Dynamic range: 110dB
Signal to Noise Ratio: 114dB
Channel separation: 108dB
Total harmonic distortion: 0.0008%
Line output: 2.5V (unbalanced), 2.5V (balanced)
Digital outputs: coaxial, optical
Power Consumption 24 Watts

Accessories: Accuphase RC-28 remote commander

Net weight (2.2 lb = 1 kg) 17.7 kg / 38 lb 15.8 oz (38.987 lb)
Mentioned in - - Manufacturers Literature (Service Info)
Literature/Schematics (1) -- Original prospect or advert (Accuphase Flyer)

Model page created by Franz Scharner. See "Data change" for further contributors.
