Tube Tester 151 ; Accurate Instrument (ID = 840033) Equipment
Accurate Instrument: Tube Tester 151 [Equipment] ID = 840033 490x768
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tube Tester 151, Accurate Instrument Co. Inc.; New York (NY):
By courtesy of guest Jerry Azzaro, San Francisco, USA.

Country:  United States of America (USA)
Manufacturer / Brand:  Accurate Instrument Co. Inc.; New York (NY)
Year: 1960 Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Tube Tester 151 - Accurate Instrument Co. Inc.;
Material Leather / canvas / plastic - over other material
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 10.5 x 3.25 x 8.87 inch / 267 x 83 x 225 mm
Notes The Tube Tester 151 has 7 sockets, 2 pin straighteners (for 7-pin and 9-pin miniature tubes) in the lower left corner, one VU meter, manual test voltage selection. Info from guest Jerry Azzaro: The operating instructions are from November 1960. He is adding: "see the operating instructions which you can see tucked into the lid in the photo. It is 40 pages long and lists hundreds of tubes. It includes a schematic for the tester. There is also a typed/photocopied 2-page supplement chart. Some tubes are listed two or three times because they require multiple tests. The tester would be quite useless without these documents!"
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Accurate Instrument Co. Inc.; New York (NY)
Here you find 9 models, 8 with images and 7 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
