Minature PA Amplifier

Minature PA Amplifier ; A.C.E. ACE Radio; (ID = 2407835) Ampl/Mixer Minature PA Amplifier ; A.C.E. ACE Radio; (ID = 2407836) Ampl/Mixer
Minature PA Amplifier ; A.C.E. ACE Radio; (ID = 2407837) Ampl/Mixer Minature PA Amplifier ; A.C.E. ACE Radio; (ID = 2407838) Ampl/Mixer
Minature PA Amplifier ; A.C.E. ACE Radio; (ID = 2407839) Ampl/Mixer
Use red slider bar for more.
Minature PA Amplifier ; A.C.E. ACE Radio; (ID = 2407835) Ampl/Mixer
A.C.E. ACE Radio;: Minature PA Amplifier [Ampl/Mixer] ID = 2407835 1400x604
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minature PA Amplifier, A.C.E. (ACE) Radio; Sydney, NSW:
Ace Radio 15W Front

Country:  Australia
Manufacturer / Brand:  A.C.E. (ACE) Radio; Sydney, NSW
Year: 1967 Category: Audio Amplifier or -mixer
Valves / Tubes 4: 6060 6BL8 6BQ5 6BQ5
Main principle Audio-Amplification
Details
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 15 W (max.)
from Radiomuseum.org Model: Minature PA Amplifier - A.C.E. ACE Radio; Sydney, NSW
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 320 x 120 x 225 mm / 12.6 x 4.7 x 8.9 inch
Net weight (2.2 lb = 1 kg) 6.5 kg / 14 lb 5.1 oz (14.317 lb)
Mentioned in -- Original prospect or advert (Electronic Australia, Nov 1967, Page 158)

Model page created by Joshua Boxer. See "Data change" for further contributors.
