AR15 ; Acoustic Research (ID = 563489) Speaker-P
Acoustic Research: AR15 [Speaker-P] ID = 563489 281x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model AR15, Acoustic Research Inc.; Cambridge, MA:
Original prospekt in 1978.

Country:  United States of America (USA)
Manufacturer / Brand:  Acoustic Research Inc.; Cambridge, MA
Year: 1978 Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: AR15 - Acoustic Research Inc.;
Material Wooden case
Dimensions (WHD) 298 x 544 x 197 mm / 11.7 x 21.4 x 7.8 inch
Notes 2-Weg-HiFi-Box mit 50 Watt Sinus, Impedanz 8 Ohm, Frequenzbereich 43-25000Hz. Tieftöner 200mm, Mittel/Hochtöner 25mm. Frequenzweiche (Übergang bei 1700 Hz). Resonanzfrequenz Tieftöner 25Hz, Hochtöner 1050Hz. Volumen: 18 Liter
Net weight (2.2 lb = 1 kg) 11 kg / 24 lb 3.7 oz (24.229 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
