518 Ch= 4W2

Admiral (brand) Continental Radio & Television Co.; Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1958 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 312173
    • alternative name: Continental Radio & TV

 Technical Specifications

  • Number of Tubes
  • 4
  • Valves / Tubes
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Line / Batteries (any type) / 117 or 7.5 & 90 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 518 Ch= 4W2 - Admiral brand Continental
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes

  • The antenna is external since the case is metal. Admiral used  chassis 4W2 in several other models such as 202, 215, 217, 218, 502, 515.

  • Author
  • Model page created by Aldo Andreani. See "Data change" for further contributors.
