Aeroscope 5K32 (Ch= 5K3)

Aeroscope 5K32 ; Admiral brand (ID = 2462296) Radio

Aeroscope 5K32 ; Admiral brand (ID = 87440) Radio

Aeroscope 5K32 ; Admiral brand (ID = 1119754) Radio

Aeroscope 5K32 ; Admiral brand (ID = 1119755) Radio

Aeroscope 5K32 ; Admiral brand (ID = 1119756) Radio

Aeroscope 5K32 ; Admiral brand (ID = 1119757) Radio
Aeroscope 5K32 ; Admiral brand (ID = 2355441) Radio Aeroscope 5K32 ; Admiral brand (ID = 2355442) Radio
Aeroscope 5K32 ; Admiral brand (ID = 2355443) Radio Aeroscope 5K32 ; Admiral brand (ID = 2355445) Radio
Aeroscope 5K32 ; Admiral brand (ID = 2355446) Radio Aeroscope 5K32 ; Admiral brand (ID = 2355447) Radio
Aeroscope 5K32 ; Admiral brand (ID = 2355448) Radio Aeroscope 5K32 ; Admiral brand (ID = 87438) Radio
Use red slider bar for more.
Aeroscope 5K32 ; Admiral brand (ID = 2355441) Radio
Admiral brand: Aeroscope 5K32 [Radio] ID = 2355441 1400x1272
Select picture or schematic to display from thumbnails on the right and click for download.
For model Aeroscope 5K32 (Ch= 5K3), Admiral (brand) Continental Radio & Television Co.; Chicago, IL:
ebay.com 183668814906 seller buba2220

Country:  United States of America (USA)
Manufacturer / Brand:  Admiral (brand) Continental Radio & Television Co.; Chicago, IL
alternative name

Continental Radio & TV
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1U4 1R5 1U4 1U5 3V4
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / =9/90, ~117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Aeroscope 5K32 - Admiral brand Continental
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

Uses Selenium rectifier. Speaker is elliptical PM 4" x 6".

Source of data Collector's Guide to Antique Radios (6th edition)
Literature/Schematics (1) Beitman Radio Diagrams, Vol. 15, 1955
Literature/Schematics (2) - - Manufacturers Literature
Literature/Schematics (3) Photofact Folder, Howard W. SAMS (Set 376 Photofact Servicer vol.38 dated 11-57)

Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
