Radio Chassis Ch= 4L1
Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Year
- 1950 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 248179
-
- alternative name: Continental Radio & TV
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: Radio Chassis Ch= 4L1 - Admiral brand Continental
- Shape
- Chassis only or for «building in»
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 91A, Folder 1 1950)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 100, Folder 1)
- Author
- Model page created by Geert Schulte. See "Data change" for further contributors.
