RC600

• Country
• United States of America (USA)

• Manufacturer / Brand
• Admiral (brand) Continental Radio & Television Co.; Chicago, IL

• Year
• 1953 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 87931

• • alternative name: Continental Radio & TV

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: RC600 - Admiral brand Continental

• Shape
• Chassis only or for «building in»

• Notes

• The Admiral model RC600 record changer is designed  to play standard 78 RPM, fine-groove 45 RPM, or long-play 33 1/3 RPM records of standard commercial dimensions. Records up to 12 inches in diameter can be played.



• Literature/Schematics (1)
• Beitman Radio Diagrams, Vol. 13, 1953

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 218, folder 2, dated 10-53)

• Author
• Model page created by Walter Wiesmüller † May 2012. See "Data change" for further contributors.
