Sheridan Ch= 16D110; Admiral of Australia (ID = 2207182) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  Admiral of Australia, Bankstown
Year: 1959 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: 6BC8 6U8 6BZ6 6BZ6 6CB6 12BY7A 6U8 6CZ5 6BU8 6CG7 6DB5 or 6EM5 6CG7 6CD6GA 6AU4 1B3GT 21CEP4
Semiconductors (the count is only for transistors) OA70 OA79 OA79 OA81 OA81 1N1169 1N1169 1N1169 1N1169
Main principle Superhet with RF-stage; ZF/IF 36000/30500 kHz; 2 AF stage(s)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 200-240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Sheridan Ch= 16D110 - Admiral of Australia,
Material Wooden case
Shape Console with any shape - in general
Notes

This 21 inch B&W television tuned the 10 then standard Australian VHF channels.

Later versions used the 6EM5 vertical output.

Literature/Schematics (1) - - Manufacturers Literature
Literature/Schematics (2) J.R. Publications Television Service Handbook (Page A9)

Model page created by Stuart Irwin. See "Data change" for further contributors.
