Y3137 "Chaperone" Ch= 4R3
Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Year
- 1962/1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 86325
-
- alternative name: Continental Radio & TV
RECONSTRUCTED LABEL
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Y3137 "Chaperone" Ch= 4R3 - Admiral brand Continental
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Notes
- The SAMS Photofact date 1-63, set 613, folder 4 shows the same information for Admiral model Y3133 and Y3137 with chassis 4R3. They are AC operated 4 tube AM receivers with electric clock. The only difference is color: Y3133 is white, Y3133 is boulder beige. Featured with 4 tuned circuits they have only local station reception.
For more information on the Y-models including colors see this link.
- Source of data
- Collector's Guide to Antique Radios (7th Edition)
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 22, 1962
- Mentioned in
- Collector's Guide to Antique Radios (6th edition)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 1-63, set 613, folder 4)
