• Country
• United States of America (USA)

• Manufacturer / Brand
• Admiral (brand) Continental Radio & Television Co.; Chicago, IL

• Year
• 1966 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 168785

• • alternative name: Continental Radio & TV

• Number of Transistors
• 10

• Semiconductors

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 4.5 cm = 1.8 inch

• Power out
• 0.3 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: YK-221GP Ch= 10B3 - Admiral brand Continental

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 72 x 111 x 32 mm / 2.8 x 4.4 x 1.3 inch

• Notes
• Chassis 10B3 in Beitman.

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 27, 1967-69 (last vol.)

• Author
• Model page created by Giuseppe Duello. See "Data change" for further contributors.
