Three Way Speaker System ADS 910

ADS, Analog & Digital Systems, Inc.; Wilmington, MA

Data
Forum
Pictures
Collections

  • Year
  • 1976
  • Category
  • Loudspeaker, headphone or earphone
  • Radiomuseum.org ID
  • 279019

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • 4 Loudspeakers
  • Power out
  • 150 W (max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Three Way Speaker System ADS 910 - ADS, Analog & Digital Systems,
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 480 x 850 x 390 mm / 18.9 x 33.5 x 15.4 inch
  • Notes

  • ADS 3 Way 4 Driver Loudspeaker System Model ADS 910.
    Frequency Response: 28Hz to 20kHz
    Power Handling: 150 Watts
    Recommended Amplifier: 15 to 300 Watts
    Crossover Frequency: 500, 4000Hz
    Impedance: 4Ω
    Sensitivity: 93dB/W/m
    Drivers:
    Bass: 2x 10" cone
    Midrange: 1x 2" dome
    Tweeter: 1x 1" soft dome
    Grille: black cloth
    Finish: walnut veneer

  • Net weight (2.2 lb = 1 kg)
  • 45.5 kg / 100 lb 3.5 oz (100.22 lb)
  • Mentioned in
  • - - Manufacturers Literature (Instruction/Owners Manual)
  • Literature/Schematics (1)
  • -- Original prospect or advert (ADS Flyer)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
