658 variante?
AEG Iberica, Madrid
- Country
- Spain
- Manufacturer / Brand
- AEG Iberica, Madrid
- Year
- 1950 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 140504
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 22 cm = 8.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 658 [variante?] - AEG Iberica, Madrid
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 580 x 400 x 230 mm / 22.8 x 15.7 x 9.1 inch
- Notes
-
The type number is not certain; there exists a slightly different model with allegedly the same type number. Verification pending.
- Author
- Model page created by Diego Fernandez-Fernandez. See "Data change" for further contributors.
