Superb 741

Superb 741; AGA and Aga-Baltic (ID = 274333) Radio
Superb 741; AGA and Aga-Baltic (ID = 97755) Radio Superb 741; AGA and Aga-Baltic (ID = 562516) Radio
Superb 741; AGA and Aga-Baltic (ID = 562508) Radio Superb 741; AGA and Aga-Baltic (ID = 562509) Radio
Superb 741; AGA and Aga-Baltic (ID = 562510) Radio Superb 741; AGA and Aga-Baltic (ID = 562513) Radio
Superb 741; AGA and Aga-Baltic (ID = 562514) Radio Superb 741; AGA and Aga-Baltic (ID = 562515) Radio
Use red slider bar for more.
Superb 741; AGA and Aga-Baltic (ID = 97755) Radio
AGA and Aga-Baltic: Superb 741 [Radio] ID = 97755 405x256
Select picture or schematic to display from thumbnails on the right and click for download.
For model Superb 741, AGA and Aga-Baltic Radio AB; Sweden

Country:  Sweden
Manufacturer / Brand:  AGA and Aga-Baltic Radio AB; Sweden
alternative name

AGA-Baltic Radio AB; Stockholm
Year: 1937/1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A3 6K7G 6Q7G 6N6G 5Y4G
Main principle Superheterodyne (common)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: Superb 741 - AGA and Aga-Baltic Radio AB;
Material Wooden case
Price in first year of sale 330.00 SFR
External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.


All listed radios etc. from AGA and Aga-Baltic Radio AB; Sweden
Here you find 254 models, 208 with images and 131 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
