4706 "Regent" Ch= 467

Air King Products Co.; Brooklyn (NY)

  • Year
  • 1946/1947
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 31637

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • AC/DC-set / 105 - 125 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: 4706 "Regent" Ch= 467 - Air King Products Co.;
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 9.5 x 6.5 x 5.5 inch / 241 x 165 x 140 mm
  • Notes
  • Cabinet available in ivory and walnut. Sams photofact set 9 folder 469-1 date 12-46 features the Air King models 4705 and 4706 as the same schematic.

    Material : Painted bakelite.

  • Net weight (2.2 lb = 1 kg)
  • 2.270 kg / 5 lb 0 oz (5 lb)
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Photofact Folder, Howard W. SAMS
