A510 "Royal Troubadour" var2
Air King Products Co.; Brooklyn (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Air King Products Co.; Brooklyn (NY)
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 72603
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Batteries (any type) / AC/DC 110 - 120 / 90 & 7.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: A510 "Royal Troubadour" [var2] - Air King Products Co.;
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
- Selenium Rectifier
See also Rider's Perpetual, Volume 18.
- Price in first year of sale
- 37.95 $
- Circuit diagram reference
- Rider's Perpetual, Volume 17 = 1948 and before
- Mentioned in
- Radio Retailing (Radio & Television R.) (May 1947 page 45.)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
