- Country
- Australia
- Manufacturer / Brand
- Peal Products, a subsidiary of Airzone (1931) Pty. Ltd., Sydney.
- Year
- 1941
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 183509
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 215; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: Peal 51MA - Peal Products, a subsidiary of
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Price in first year of sale
- 16.80 AUS £
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. IV
- Mentioned in
- Mingay's "Radio Diagram & I.F. Index
- Literature/Schematics (1)
- Australian Official Radio Service Manual AORSM (Volume 4, 1941, Page 243.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
