AD-WX110

AD-WX110; Aiwa Co. Ltd.; Tokyo (ID = 2502513) R-Player
Use red slider bar for more.
AD-WX110; Aiwa Co. Ltd.; Tokyo (ID = 2502513) R-Player
Aiwa Co. Ltd.; Tokyo: AD-WX110 [R-Player] ID = 2502513 1038x686
Select picture or schematic to display from thumbnails on the right and click for download.
For model AD-WX110, Aiwa Co. Ltd.; Tokyo:
Funkschau 21/1983, S. 62

Country:  Japan
Manufacturer / Brand:  Aiwa Co. Ltd.; Tokyo
Year: 1983–1986 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 120;220;240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: AD-WX110 - Aiwa Co. Ltd.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 330 x 107 x 306 mm / 13 x 4.2 x 12 inch
Notes HiFi-Cassettendeck mit Dolby B + C; 20 - 18.000 Hz (Metal Tape).
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)
Source of data -- Original prospect or advert
Mentioned in Funkschau (21/1983, S. 62, 63 /Gebrauchstest)

Model page created by Franz Scharner. See "Data change" for further contributors.
