Cassette Recorder VZRS Voice Zoom Recording System TP-560

ID = 123630

{gbW: "933", gbH: "700", mW: "500", mH: "375", kb: "72 KB", notes: "For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:[br]AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Frontansicht", title: "Aiwa Co. Ltd.; Tokyo Cassette Recorder VZRS Voice Zoom Recording System TP-560 from Knut Rothstein (1)", ite: "1"} {gbW: "933", gbH: "700", mW: "500", mH: "375", kb: "69 KB", notes: "For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:[br]AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Draufsicht", title: "Aiwa Co. Ltd.; Tokyo Cassette Recorder VZRS Voice Zoom Recording System TP-560 from Knut Rothstein (1)", ite: "1"} {gbW: "933", gbH: "700", mW: "500", mH: "375", kb: "53 KB", notes: "For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:[br]AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Typenschild", title: "Aiwa Co. Ltd.; Tokyo Cassette Recorder VZRS Voice Zoom Recording System TP-560 from Knut Rothstein (1)", ite: "1"} {gbW: "933", gbH: "700", mW: "500", mH: "375", kb: "63 KB", notes: "For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:[br]AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Seitenansicht", title: "Aiwa Co. Ltd.; Tokyo Cassette Recorder VZRS Voice Zoom Recording System TP-560 from Knut Rothstein (1)", ite: "1"} {gbW: "933", gbH: "622", mW: "500", mH: "333.0", kb: "77 KB", notes: "For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:[br]AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Innenansicht1", title: "Aiwa Co. Ltd.; Tokyo Cassette Recorder VZRS Voice Zoom Recording System TP-560 from Knut Rothstein (1)", ite: "1"} {gbW: "933", gbH: "541", mW: "500", mH: "289.0", kb: "57 KB", notes: "For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:[br]AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Innenansicht3", title: "Aiwa Co. Ltd.; Tokyo Cassette Recorder VZRS Voice Zoom Recording System TP-560 from Knut Rothstein (1)", ite: "1"} {gbW: "933", gbH: "622", mW: "500", mH: "333.0", kb: "79 KB", notes: "For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:[br]AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Verpackung", title: "Aiwa Co. Ltd.; Tokyo Cassette Recorder VZRS Voice Zoom Recording System TP-560 from Knut Rothstein (1)", ite: "1"}

Cassette Recorder VZRS Voice Zoom Recording System TP-560; Aiwa Co. Ltd.; Tokyo (ID = 406338) R-Player

Cassette Recorder VZRS Voice Zoom Recording System TP-560; Aiwa Co. Ltd.; Tokyo (ID = 406337) R-Player

Cassette Recorder VZRS Voice Zoom Recording System TP-560; Aiwa Co. Ltd.; Tokyo (ID = 406343) R-Player

Cassette Recorder VZRS Voice Zoom Recording System TP-560; Aiwa Co. Ltd.; Tokyo (ID = 406339) R-Player

Cassette Recorder VZRS Voice Zoom Recording System TP-560; Aiwa Co. Ltd.; Tokyo (ID = 406340) R-Player

Cassette Recorder VZRS Voice Zoom Recording System TP-560; Aiwa Co. Ltd.; Tokyo (ID = 406344) R-Player

Use red slider bar for more.

Aiwa Co. Ltd.; Tokyo: Cassette Recorder VZRS Voice Zoom Recording System TP-560 [R-Player] ID = 406338 933x700

Select picture or schematic to display from thumbnails on the right and click for download.

For model Cassette Recorder VZRS Voice Zoom Recording System TP-560, Aiwa Co. Ltd.; Tokyo:
AIWA-Kassetten-Rekorder TP-560, Ser.Nr. LY0 64775, Frontansicht

Country:

Japan

Manufacturer / Brand:

Aiwa Co. Ltd.; Tokyo

Year: 1996

Category: Sound/Video Recorder and/or Player

Semiconductors (the count is only for transistors)

Semiconductors present.

Main principle	Audio-Amplification
Wave bands	- without
Details	Cassette-Recorder or -Player
Power type and voltage	Dry Batteries / 2 × 1,5 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.6 cm = 1.4 inch
Power out	0.15 W (unknown quality)
from Radiomuseum.org	Model: Cassette Recorder VZRS Voice Zoom Recording System TP-560 - Aiwa Co. Ltd.; Tokyo
Material	Modern plastics (no Bakelite or Catalin)
Shape	Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD)	118 x 94 x 35 mm / 4.6 x 3.7 x 1.4 inch
Notes	Kassetten-Rekorder mit Aufnahmefunktion Besonderheiten: zuschaltbare Rauschunterdrückung bei Sprachaufnahmen, Vorwahlmöglichkeit des minimalen Aufnahmepegels, Anschlussmöglichkeit für externes Mikrofon, 3 Bandgeschwindigkeiten, mechanisches Bandzählwerk Frequenzgang 150 - 8000 Hz bei 4.75 cm/s Eingebautes Elektret-Mikrofon Aufnahme mit Gleichstrom-Vormagnetisierung hergestellt in China
Net weight (2.2 lb = 1 kg)	0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale	100.00 DM

Model page created by Knut Rothstein. See "Data change" for further contributors.
