Direct Drive Turntable System AP-2300

Direct Drive Turntable System AP-2300; Aiwa Co. Ltd.; Tokyo (ID = 1499852) R-Player
Direct Drive Turntable System AP-2300; Aiwa Co. Ltd.; Tokyo (ID = 1499713) R-Player
Use red slider bar for more.
Direct Drive Turntable System AP-2300; Aiwa Co. Ltd.; Tokyo (ID = 1499713) R-Player
Aiwa Co. Ltd.; Tokyo: Direct Drive Turntable System AP-2300 [R-Player] ID = 1499713 933x749
Select picture or schematic to display from thumbnails on the right and click for download.
For model Direct Drive Turntable System AP-2300, Aiwa Co. Ltd.; Tokyo:
Scan aus Aiwa-Prospekt

Country:  Japan
Manufacturer / Brand:  Aiwa Co. Ltd.; Tokyo
Year: 1980 ?? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Direct Drive Turntable System AP-2300 - Aiwa Co. Ltd.; Tokyo
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 125 x 420 x 360 mm / 4.9 x 16.5 x 14.2 inch
Notes

HiFi-Plattenspieler mit 2 Geschwindigkeiten. Antrieb: 2 Phasen, 8-Pol Linear Tourque DC-Servomotor.

Mentioned in -- Original prospect or advert

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
