For model Stereo Cassette Deck AD-F810, Aiwa Co. Ltd.; Tokyo:
Original prospekt.

Country:  Japan
Manufacturer / Brand:  Aiwa Co. Ltd.; Tokyo
Year: 1992 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Cassette Deck AD-F810 - Aiwa Co. Ltd.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 140 x 318 mm / 16.9 x 5.5 x 12.5 inch
Notes

Frontloading 3-Head Stereo Cassette Deck with Dolby B + C, MPX Filter, Dolby HX Pro and Metal Tape Capability.
Digital Peak-Reading Meters, Peak Hold.

Type: 3-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.8 cm/s
Heads: 1 x record, 1 x playback, 1 x erase
Motor: 1 x reel, 1 x capstan
Tape Type: type I, CrO2, Metal
Noise Reduction: B, C
Frequency Response: 15Hz to 20kHz  (Metal tape)
Signal to Noise Ratio: 80dB  (dolby C)
Wow and Flutter: 0.035%
Input: 50mV (line)
Output: 0.37V (line)

Net weight (2.2 lb = 1 kg) 4.9 kg / 10 lb 12.7 oz (10.793 lb)
Price in first year of sale 400.00 $
