Stereo Turntable System LX-770

Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424521) R-Player Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424522) R-Player
Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424525) R-Player Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424526) R-Player
Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424527) R-Player Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424529) R-Player
Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424530) R-Player Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424531) R-Player
Use red slider bar for more.
Stereo Turntable System LX-770; Aiwa Co. Ltd.; Tokyo (ID = 2424521) R-Player
Aiwa Co. Ltd.; Tokyo: Stereo Turntable System LX-770 [R-Player] ID = 2424521 1024x685
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Turntable System LX-770, Aiwa Co. Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Aiwa Co. Ltd.; Tokyo
Year: 1986 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
schematic requested
Main principle Audio-Amplification
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Turntable System LX-770 - Aiwa Co. Ltd.; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Book-shelf unit.
Dimensions (WHD) 330 x 85 x 330 mm / 13 x 3.3 x 13 inch
Notes Drive system: Frequency generated direct drive system
Motor: 4-phase 8-pole linear torque DD hall motor
Speeds: 33-1/3 and 45 rpm
Wow & flutter: 0.045% (WRMS), S/N ratio: 75 dB (DIN-B)
Tonearm type: Linear tracking type, straight dynamic balanced type
Tracking error: 10'
Cartridge type: VM type
Frequncy response: 10-20.000 Hz
Output voltage: 2.5 mV (1kHz 3.45 cm/sec)

Feautures:
- Full automatic system
- Track indexing
- Track programming (Up to 7 tracks)
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)

Model page created by Jaroslav Hlavaty. See "Data change" for further contributors.
