TP-12E

TP-12E; Aiwa Co. Ltd.; Tokyo (ID = 559760) R-Player TP-12E; Aiwa Co. Ltd.; Tokyo (ID = 1835033) R-Player
TP-12E; Aiwa Co. Ltd.; Tokyo (ID = 1835035) R-Player TP-12E; Aiwa Co. Ltd.; Tokyo (ID = 1835036) R-Player
Use red slider bar for more.
TP-12E; Aiwa Co. Ltd.; Tokyo (ID = 559760) R-Player
Aiwa Co. Ltd.; Tokyo: TP-12E [R-Player] ID = 559760 450x426
Select picture or schematic to display from thumbnails on the right and click for download.
For model TP-12E, Aiwa Co. Ltd.; Tokyo:
Original prospekt in 1977.

Country:  Japan
Manufacturer / Brand:  Aiwa Co. Ltd.; Tokyo
Year: 1977 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 1:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Dry Batteries / 4 × 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: TP-12E - Aiwa Co. Ltd.; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 175 x 176 x 44 mm / 6.9 x 6.9 x 1.7 inch
Notes Compact Recorder mit Tonregler,
variable Geschwindigkeit, Zählwerk, Pausentaste, Autostop, Repetiertaste, ALC, Frequenzgang 100-10000Hz. 1 Transistor, 2 IC's, 2 Dioden.
Zubehör: Ohrhörer, Demo-Cassette, 4 Batterien UM-2.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
