Table Model Panel GPO Nr.2109 w/o lid

Table Model Panel GPO Nr.2109; AJS; A.J. Stevens & (ID = 521504) Radio
Table Model Panel GPO Nr.2109; AJS; A.J. Stevens & (ID = 521240) Radio Table Model Panel GPO Nr.2109; AJS; A.J. Stevens & (ID = 521474) Radio
Table Model Panel GPO Nr.2109; AJS; A.J. Stevens & (ID = 521470) Radio Table Model Panel GPO Nr.2109; AJS; A.J. Stevens & (ID = 521471) Radio
Table Model Panel GPO Nr.2109; AJS; A.J. Stevens & (ID = 521472) Radio
Use red slider bar for more.
Table Model Panel GPO Nr.2109; AJS; A.J. Stevens & (ID = 521240) Radio
AJS; A.J. Stevens &: Table Model Panel GPO Nr.2109 [Radio] ID = 521240 723x598
Select picture or schematic to display from thumbnails on the right and click for download.
For model Table Model Panel GPO Nr.2109 w/o lid, AJS; A.J. Stevens & Co Ltd; Wolverhampton:
our receiver is not equiped with the original Mullard valves.

Country:  Great Britain (UK)
Manufacturer / Brand:  AJS; A.J. Stevens & Co Ltd; Wolverhampton
Brand

A.J.S.
Year: 1923/1924 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4:
Main principle TRF with regeneration
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Table Model Panel GPO Nr.2109 [w/o lid] - AJS; A.J. Stevens & Co Ltd;
Material Wooden case, TUBES VISIBLE.
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 16.5 x 18.5 x 12 inch / 419 x 470 x 305 mm
Notes The Panel GPO Reg.No.2109 is employed in four cabinet versions: Table Model (open, without lid); Table deLuxe (with lid); Slant Panel; Pedestal. Choice of oak, walnut, or mahogany.
External source of data Bev Parker

Model page created by a member from B. See "Data change" for further contributors.



All listed radios etc. from AJS; A.J. Stevens & Co Ltd; Wolverhampton
Here you find 34 models, 21 with images and 3 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
