Jonny 6 Transistors; Unknown - CUSTOM (ID = 1519894) Radio
Unknown - CUSTOM: Jonny 6 Transistors [Radio] ID = 1519894 900x668
Select picture or schematic to display from thumbnails on the right and click for download.
For model Jonny 6 Transistors, Unknown - CUSTOM BUILT: Hong Kong (HK)

Country:  Hong Kong
Manufacturer / Brand:  Unknown - CUSTOM BUILT: Hong Kong (HK)
Year: 1967 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: 2SB33 2SB33
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Jonny 6 Transistors - Unknown - CUSTOM BUILT: Hong
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 112 x 65 x 31 mm / 4.4 x 2.6 x 1.2 inch
Notes 4 transistor non siglati.
4 transistors without designation.
Net weight (2.2 lb = 1 kg) 0.184 kg / 0 lb 6.5 oz (0.405 lb)
Source of data - - Data from my own collection
Mentioned in -- Original-techn. papers.

Model page created by Carlo Cossa. See "Data change" for further contributors.
