Rekord {Рекорд} 47

Rekord {Рекорд} 47; Berdsk Radio Works (ID = 156360) Radio
Rekord {Рекорд} 47; Berdsk Radio Works (ID = 326492) Radio Rekord {Рекорд} 47; Berdsk Radio Works (ID = 326493) Radio
Rekord {Рекорд} 47; Berdsk Radio Works (ID = 319443) Radio Rekord {Рекорд} 47; Berdsk Radio Works (ID = 158957) Radio
Rekord {Рекорд} 47; Berdsk Radio Works (ID = 158958) Radio
Use red slider bar for more.
Rekord {Рекорд} 47; Berdsk Radio Works (ID = 326492) Radio
Berdsk Radio Works: Rekord {Рекорд} 47 [Radio] ID = 326492 864x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rekord {Рекорд} 47, Berdsk Radio Works

Country:  Soviet Union
Manufacturer / Brand:  Berdsk Radio Works
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6А7 6К7 6Г7 30П1С 30Ц1М
Main principle Superheterodyne (common); ZF/IF 110 kHz
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 127;220 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 15 cm = 5.9 inch
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: Rekord {Рекорд} 47 - Berdsk Radio Works
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 350 x 265 x 180 mm / 13.8 x 10.4 x 7.1 inch
Notes

Produced in  past SU -  Irkutsk,  Petropavlovsk and Aleksandrov  Radio Works too.

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)

Model page created by a member from LV. See "Data change" for further contributors.
