VHF/UHF-FM-Triband-Handy DJ-G7 (E)

VHF/UHF-FM-Triband-Handy DJ-G7 ; Alinco Inc.; Osaka (ID = 2058142) Amat TRX

VHF/UHF-FM-Triband-Handy DJ-G7 ; Alinco Inc.; Osaka (ID = 2058146) Amat TRX
VHF/UHF-FM-Triband-Handy DJ-G7 ; Alinco Inc.; Osaka (ID = 2058139) Amat TRX VHF/UHF-FM-Triband-Handy DJ-G7 ; Alinco Inc.; Osaka (ID = 823198) Amat TRX
Use red slider bar for more.
VHF/UHF-FM-Triband-Handy DJ-G7 ; Alinco Inc.; Osaka (ID = 2058139) Amat TRX
Alinco Inc.; Osaka: VHF/UHF-FM-Triband-Handy DJ-G7 [Amat TRX] ID = 2058139 559x2100
Select picture or schematic to display from thumbnails on the right and click for download.
For model VHF/UHF-FM-Triband-Handy DJ-G7 (E), Alinco Inc.; Osaka:
Aus Funkamateur (FA) 9/2009

Country:  Japan
Manufacturer / Brand:  Alinco Inc.; Osaka
Year: 2009 Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 51650/450 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Storage and/or dry batteries / 7,4 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: VHF/UHF-FM-Triband-Handy DJ-G7 - Alinco Inc.; Osaka
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 60 x 115 x 30 mm / 2.4 x 4.5 x 1.2 inch
Notes Alinco VHF/UHF-FM-Triband-Handfunkgerät mit Breitbandempfänger DJ-G7.
Frequenzbereiche RX/TX: 144...146, 430...440 MHz und 1240...1300 MHz, RX (E-Version): zusätzlich 522...1620 kHz und 87,6...107,9 MHz, in der T-Version: 0,531...1300 MHz; Pout 2 m: 2 W, 70 cm: 1,5 W, 23 cm: 1 W.
Wasserdicht gemäß IP-X7 (30 Minuten in 1 m Tiefe); Buchse für externe Stromversorgung (13,8 V); VOX-Funktion; CTCSS- und DCS-Coder und Decoder; DTMF-Tastatur; Channelscope-Funktion für 11 Kanäle; über 1000 Speicher; APO- und TOT-Funktion; CPU-Takt umschaltbar.
Net weight (2.2 lb = 1 kg) 0.296 kg / 0 lb 10.4 oz (0.652 lb)
Price in first year of sale 395.00 EUR
Collectors' prices
Mentioned in FA 9/09

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
