For model DX-R8E, Alinco Inc.; Osaka:
FA 3/11

Country:  Japan
Manufacturer / Brand:  Alinco Inc.; Osaka
Year: 2011 Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 71750/455 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / DC 13,8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: DX-R8E - Alinco Inc.; Osaka
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 240 x 94 x 255 mm / 9.4 x 3.7 x 10 inch
Notes Alinco Kommunikationsempfänger DX-R8E.
Frequenzbereich: 0,15 ... 35 MHz; Betriebsarten: SSB, AM, CW, FM.
Bedienteil abnehmbar, Betrieb mit abgesetztem Bedienteil möglich; zwei VFOs; ZF-Shift-Funktion (max. ±1,5 kHz); Schmalbandfilter für CW, SSB und AM; stabiler TCXO mit ±1 ppm; Ausschalt- und APO-Funktion; Stromaufnahme bei max. Lautstärke: 1 A.
Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)
Price in first year of sale 469.00 EUR
Collectors' prices
Mentioned in FA 3/11

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
