• Country
• United States of America (USA)

• Manufacturer / Brand
• Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)

• Year
• 1942 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 32314

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 14

• Valves / Tubes
• 6SK7 6SA7 6AC7 6AC7 6U5 6SJ7 6H6 6H6 6SJ7 6SJ7 6J5 6V6G 6V6G 5Y3G

• Main principle
• Superhet with RF-stage; ZF/IF 4300/465 kHz

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• from Radiomuseum.org
• Model: D-182 [6V6 power tubes] - Allied Radio Corp. Knight,

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 14 = 1944 = before 1943

• Other Models

• Here you find 1036 models, 639 with images and 680 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
