• Country
• United States of America (USA)

• Manufacturer / Brand
• Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)

• Year
• 1956 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 136124

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12AY7 12AX7 6AQ5 6AQ5 5Y3GT

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 115V = 110 -120 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Knight 99RZ177 - Allied Radio Corp. Knight,

• Shape
• Tablemodel, with any shape - general.

• Notes

• SAMS photofact, date 9-57, set 372, folder 8, features the Allied radio Knight models 99RZ177 and 99RZ936 as the same schematic.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 372 folder 8 date 9-57)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
