• Country
• United States of America (USA)

• Manufacturer / Brand
• Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 179626

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• 6CB6 6AB4 12AT7 6CB6 6BE6 6CB6 6CB6 6AU6 6AU6 6AL5 12AU7 6X4

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 105 -125 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Knight KN-110 Ch= 92SX403 - Allied Radio Corp. Knight,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 13.5 x 4 x 10 inch / 343 x 102 x 254 mm

• Notes

• The Allied Radio Model KN-110 is an AC operated 9 tube FM-AM tuner.

  Brown leather-tone finish case, brushed brass panel and black trim.
  Tuning Meter, AFC
  Shpg. wt: 17 lbs.


• Price in first year of sale
• 99.50 USD

• Source of data
• -- Original prospect or advert

• Mentioned in
• Allied Radio Catalog 180 - 1959 page 39

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 8-58, Set 409, Folder 11)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
