Alpage Stereo Cassette Tape Deck FL-8000

Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028806) R-Player Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028807) R-Player
Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028808) R-Player Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028783) R-Player
Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028809) R-Player Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028784) R-Player
Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028785) R-Player Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028810) R-Player
Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028817) R-Player
Use red slider bar for more.
Alpage Stereo Cassette Tape Deck FL-8000; Alpine Electronics, (ID = 2028806) R-Player
Alpine Electronics,: Alpage Stereo Cassette Tape Deck FL-8000 [R-Player] ID = 2028806 1400x681
Select picture or schematic to display from thumbnails on the right and click for download.
For model Alpage Stereo Cassette Tape Deck FL-8000, Alpine Electronics, Tokyo:
Ebay Auction

Country:  Japan
Manufacturer / Brand:  Alpine Electronics, Tokyo
Brand

Alpage
Year: 1979/1980 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 38:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Alpage Stereo Cassette Tape Deck FL-8000 - Alpine Electronics, Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 435 x 150 x 255 mm / 17.1 x 5.9 x 10 inch
Notes

Frontloading 3-Head Stereo Cassette Tape Deck with Dolby B, Double Dolby NR Circuits and Chrome Tape Capability.
3-Digit Mechanical Counter, Analog Needle Meters. Cassette Back Light.
Closed Loop Dual Capstan.

Frequency Response: 30Hz to 18kHz (Cr02 tape)
Signal to Noise Ratio: 65dB (dolby B)
Wow and Flutter: 0.04%
Total Harmonic Distortion: 1.2%
Input: 100mV (line), 0.2mV (mic)
Output: 0.42V (line)
Finish: Silver
Power Requirements:
European A model - 110/127/220/240VAC, 50/60Hz
European B model - 220VAC, 50Hz
Others - 120VAC, 60Hz
Power COnsumption 35 Watts
Semi-Conductors: 38x transistors, 4x IC's, 23x diodes, 1x Zener diode, 1x Thryritor

Net weight (2.2 lb = 1 kg) 6.7 kg / 14 lb 12.1 oz (14.758 lb)
Mentioned in - - Manufacturers Literature (Catalogue 'Stereo Cassette Decks')
