• Country
• United States of America (USA)

• Manufacturer / Brand
• Ameritron; Starkville (MS)

• Year
• 1990 ??

• Category
• RF (Radio Frequency-) Amplifier

• Radiomuseum.org ID
• 233566

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 3CX1500A7 or 8877

• Main principle
• Radio Frequency Amplification only

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 208; 220; 235; 245 50/60Hz Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: AL-1500 - Ameritron; Starkville MS

• Shape
• Boatanchor (heavy military or commercial set >20 kg).

• Dimensions (WHD)
• 17 x 10 x 18.5 inch / 432 x 254 x 470 mm

• Notes

• Linear amplifier for 80, 40, 20, 17, 15, 12 and 10 meter amateur bands. 1500 watts output. Various submodels for US domestic and export sales offered. Price (2013) is for AL-1500XQCE "CE" certified model, US model AL-1500 sells for 4195 $ (1990 price 2625 $). Shipped in three packages (amplifier, transformer, tube).

• Net weight (2.2 lb = 1 kg)
• 77 lb (77 lb 0 oz) / 34.958 kg

• Price in first year of sale
• 4,595.00 USD

• Mentioned in
• - - Manufacturers Literature

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Götz Linss † 27.06.21. See "Data change" for further contributors.
