For model A56, Amplix (CGTVE); Paris:
From Radiofil N° 66

Country:  France
Manufacturer / Brand:  Amplix (CGTVE); Paris
Year: 1948 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6E8 6K7 6Q7 6V6G 5Y3
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 15 cm = 5.9 inch
Power out
from Radiomuseum.org Model: A56 - Amplix CGTVE; Paris
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 400 x 300 x 225 mm / 15.7 x 11.8 x 8.9 inch
Net weight (2.2 lb = 1 kg) 7.6 kg / 16 lb 11.8 oz (16.74 lb)
Mentioned in Publié dans Radiofil N° 66

Model page created by Bekir Yurdakul. See "Data change" for further contributors.
