For model A57, Amplix (CGTVE); Paris

Country:  France
Manufacturer / Brand:  Amplix (CGTVE); Paris
Year: 1945 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 5Y3GB 6E8 6H8 6M7 6V6G
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
Power out
from Radiomuseum.org Model: A57 - Amplix CGTVE; Paris
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 440 x 253 x 313 mm / 17.3 x 10 x 12.3 inch
Net weight (2.2 lb = 1 kg) 9.3 kg / 20 lb 7.8 oz (20.485 lb)

Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.
